Operation:
• Load the impact body
• Place the impact body on your test piece
• Push the button to begin testing and obtain
reading
Standard Accessories:
• Base instrument
• Impact device G (“D” PHT-1700, "DL" PHT-1740)
• Calibrated test block
• Custom carry case
• Cleaning brush
• Operation manual
Functions:
• Easy to use keypad operation
• Large LCD display with back light
• Automatic conversions to: Brinell, Rockwell,
Vicker and Share
• Automatic mean value
• Data storage capacity
Specifications:
• Accuracy: +/- 0.5% (referred to L=800,
• Repeatability accuracy: +/- 4L units) L=Leeb
• Measuring range: 200-960 HL
• Materials: steel & cast steel, alloy tool
steel, stainless steel, grey cast iron, spheroidal
iron, cast aluminum, brass, bronze, wrought copper
alloy.
• Battery type: AAA alkaline (2)
• Operating temperature: 5-104 degrees F
• Dimensions: 108 x 62 x 25mm
• Weight: 230 grams
Options:
|
